Primary bladder neck obstruction: musculoskeletal findings at imaging

Camerota T C1, Broglia D2

Research Type


Abstract Category


Abstract 394
Open Discussion ePosters
Scientific Open Discussion ePoster Session 21
Thursday 30th August 2018
13:55 - 14:00 (ePoster Station 8)
Exhibition Hall
Imaging Bladder Outlet Obstruction Urgency/Frequency
1. Urology, Department of Surgery, IRCCS ICS Maugeri, Pavia, Italy, 2. Radiology Unit, Istituto di Cura Città di Pavia, Pavia, Italy

Tommaso Ciro Camerota




Hypothesis / aims of study
Primary bladder neck obstruction (PBNO) is a poorly understood benign urological condition, defined as an inappropriate or inadequate relaxation of the bladder neck during micturition [1]. It was previously hypothesized the existence of a possible correlation between altered biomechanics of the pelvis and urethral sphincters activity in male patients reporting voiding dysfunction in the absence of neurological or orthopedic signs [2]. Therefore, we decided to investigate whether a correlation and/or a cause-effect relationship may exist between these two conditions.
Study design, materials and methods
Consecutive patients diagnosed with PBNO by the same urologist at our Institution were enrolled in the present study. All the subjects underwent deep anamnestic collection, careful characterization of the reported symptoms, accurate physical examination, urinalysis, patient reported outcome measures, frequency-volume chart, uroflowmetry with post-void residual urine, abdominal ultrasound, outpatient flexible urethrocystoscopy, pain assessment, and second level imaging (alternatively, full spine X-ray or pelvic-perineal MRI). Axial, coronal, and sagittal T1W, T1TSE, DPFS, STIR images (depending on the 1.5T or 3T MR scanner) were obtained in 22 subjects; full spine X-ray on a single image was obtained from 35 additional subjects. MRI were performed by the same radiologist, while X-ray images were reviewed by the same specialist.
57 newly diagnosed male patients with PBNO were enrolled in the study; mean age at diagnosis was 39.6 ± 8.6 years. None of the performed imaging showed normal findings. When compared to normalcy, the major pathological findings at full spine X-ray were lumbar hyperlordosis, horizontalization of the sacrum and increase of the sacral slope, hooked coccyx, anterior tilt of the pelvis, lower limb length discrepancy, variable degrees of scoliosis, ischiatic outlet asymmetry (sacrotuberous and sacroischiatic ligaments; piriformis and internal obturator muscles), partial or complete congenital sacralization of L5 vertebrae, mild anterolisthesis of L5 on S1, radiographic L5-S1 disk height reduction. The main anomalies (skeletal or muscular) identified at MRI were external urethral muscle thickening, hooked coccyx or its anterior angulation [Figure 1], ischiofemoral impingement [Figure 2], sacroiliac joint sclerosis or sacroiliitis, sacrotuberous ligament thickening, piriformis muscle contraction or hypertrophy, pubo-rectal muscle hypertrophy, levator ani muscle thickening, pelvic upslip or rotation, sclerosis or erosion at the pubic symphysis, sacralization or hemisacralization of L5.
Interpretation of results
The identification of pathological characteristics at full spine X-ray and MRI was based on known morphological presentation in the normal male and on comparison with anatomy. None of the enrolled subjects perceived postural defects. All the subjects presented various degree of discordances from normalcy; some of these pathological aspects were recurrent, but unfortunately a unique common pattern was not identified. Nevertheless, at MRI we were able to categorize abnormalities into four groups: 1. hypertrophy or hypertonicity of pelvic floor muscles, which were present – with different degrees – in all the 22 subjects; 2. tendon inflammation; 3. joints inflammation or sclerosis (e.g. sacroiliac or pubic symphysis); 4. skeletal abnormalities (e.g. anterolisthesis or hooked coccyx). No relevant differences in diagnostic quality were noticed between the two MR scanners (1.5T versus 3T). The observations provided with our research seems to be coherent with previously published hypothesis [2] and gait analysis evaluations in subjects with chronic voiding dysfunction [3].
Concluding message
Postural imbalances and musculoskeletal modifications seems to be strictly associated with PBNO in male patients. To date, it is not known whether a cause-effect mechanism is present. Nevertheless, we suggest to introduce second level imaging (such as full spine X-ray or pelvic-perineal MRI) in selected male patients with chronic voiding symptoms, to better define clinical features.
Figure 1
Figure 2
  1. Nitti VW et al, Primary bladder neck obstruction in men and woman. Rev Urol 2005; 7:A12-7
  2. Camerota TC, Zago M, Pisu S, Ciprandi D, Sforza C. Primary bladder neck obstruction may be determined by postural imbalances. Med Hypotheses. 2016 Dec;97:114-116
  3. Zago M, Camerota TC, Pisu S, Ciprandi D, Sforza C. Gait analysis of young male patients diagnosed with primary bladder neck obstruction. J Electromyogr Kinesiol. 2017 Aug;35:69-75
Funding None Clinical Trial No Subjects Human Ethics Committee Maugeri Helsinki Yes Informed Consent Yes
