Electrical activity of pelvic floor muscles of continent and incontinent women in different positions: preliminary results

Alvares C1, Lemos A1, Matos Y C C1, Passos J1, Brasil C1, Campos R1, Novais L1, Sodré D1, Matos J C1, Lordelo P1

Research Type


Abstract Category

Anatomy / Biomechanics

Abstract 555
Open Discussion ePosters
Scientific Open Discussion ePoster Session 28
Friday 31st August 2018
12:55 - 13:00 (ePoster Station 7)
Exhibition Hall
Incontinence Pelvic Floor Female Biomechanics
1. Pelvic Floor Care Center (CAAP), Bahiana School of Medicine and Public Health

Cecilia Alvares




Hypothesis / aims of study
The pelvic floor muscles (PFMs) are fundamental for the mechanism of urinary continence, so it is important to measure the electrical activity to evaluate its function (1), especially in different positions. One of the forms of evaluation is electromyography (2). This study aims to compare the electrical activity of PFMs in the supine position and orthostasis of women with urinary incontinence (UI) and without loss.
Study design, materials and methods
Cross-sectional study composed of women with UI and continents. Pregnant and / or obese women were excluded.
The evaluation of the myoelectric activation of MPF was performed through a data acquisition system using surface electromyography (EMG) sensors from Miotec®. The electromyograph has the resolution of 16 bits, the maximum sample rate of 2000 samples per second, 8 input channels. The electromyography sensor has 5.0 V supply voltage, maximum input voltage between 1 mV per gain 2,000 and 8 mV per gain 250. Two-pole low-pass active filter with cutoff frequency at 1 kHz eliminates unwanted high frequencies.
The self-adhesive and disposable surface electrodes of the Medi-trace brand (model: 31118733) circular format, 30 mm diameter, were used in the region of the perineum around the anus. To reduce the impedance, tricotomy was requested in this region as well as emptying the bladder before collection. The volunteers were placed in dorsal decubitus, in the position of adapted lithotomy (with hip and knee in flexion superior to 90º). The place for placement of the electrodes was lightly sanded and sanitized with alcohol gel and disposable towel. After drying the region with a disposable towel, a pair of surface electrodes with a distance of 2cm between the centers were placed in the perineal positions of four and ten of an analog clock. (Figure 1)
A computerized electromyograph with surface electrodes in the perianal region was used to evaluate basal muscle tone (BT), maximal voluntary contraction (MVC) and mean value of tonic (TC) and phasic (FC) contractions, in the supine and orthostatic positions.
Twenty women were collected in each group, with mean age of 47.1 ± 7.77 for incontinent and 43.5 ± 8.4 for continent. The supine muscle strength of 3 (3-3) in the incontinent group (IG), and 4 (03-04) for the control group (CG) and the loss of light urine, 6 (3-13) grams in the IG. The values of BT, TC and FC in supine for the IG were, respectively, 3.1 (2.5-8.6), 16.7 (12.6-29.7) and 39.1 (24.2 -53.7), orthostasis were, 4.1 (2.9-8.4), 21.2 (8.8-26.4) and 34.4 (23.6-42.1). In CG, supine and orthostatic values, respectively, were for BT: 10 (4.5-11.3) and 10.5 (6.4-12.2); TC: 35.2 (21.3-52.5) and 35.1 (21.8-51.0), and FC: 37.3 (26.7-62.8) and 33.5 (28, 2-48.5). There was no statistical significance in the intragroup comparison (p> 0.05), only in the intergroup evaluation in BT and TC in both positions (p <0.05).
Interpretation of results
The deficiency in the tonic contraction of PFMs in incontinent women is in agreement with previous study (3).
Concluding message
It can be noticed that there is a decrease in the electrical activity of BT and TC in the IG when compared to the CG, in both positions.
Figure 1
  1. HAYLEN, B.T., et al. An International Urogynecological Association (IUGA)/International Continence Society (ICS) Joint Report on the Terminology for Female Pelvic Floor Dysfunction. Neurourology and Urodynamics, v. 29, p. 4–20, 2010
  2. KESHWANI, N., MCLEAN, L. State of the Art Review: Intravaginal Probes for Recording Electromyography from the Pelvic Floor Muscles. Neurourology and Urodynamics, DOI 10.1002/nau, 2013.
  3. CHMIELEWSKA, D., et al. Impact of Different Body Positions on Bioelectrical Activity of the Pelvic Floor Muscles in Nulliparous Continent Women. BioMed Research International, DOI: 10.1155/2015/905897, 2015.
<span class="text-strong">Funding</span> Foundation for Research Support of the State of Bahia (FAPESB) and National Council for Scientific and Technological Development (CNPq) <span class="text-strong">Clinical Trial</span> No <span class="text-strong">Subjects</span> Human <span class="text-strong">Ethics Committee</span> Committee of Ethics and Research of the Escola Bahiana de Medicina e Saúde Pública <span class="text-strong">Helsinki</span> Yes <span class="text-strong">Informed Consent</span> Yes
